MG555 DC Gearmotors - Flat

USD 14.58 MSRP

Key Data

Gearbox Weight: 494 g
Rated Voltage: 12 V
Rated Speed: 200 rpm
Rated Torque: 1699 gf·cm
Rated Power: 3488 W

Motor Options6 variants

DC555 12V 3000 RPM

Gearbox Options13 variants

MG 13:1

Request customization

Model & Specification Comparison

Motors 6 options

55512300 DC555 12V 3000 RPM In stock 99

Gearboxes 13 options

MG1300 MG 13:1 In stock 99

Product specifications
Product Model	MG555123000-
Gearbox Weight	494 g
Rated Voltage	12 V
No Load Speed	230.769231 rpm
Rated Speed	200 rpm
No Load Current	180 mA
Rated Current	600 mA
Stall Current	3,100 mA
Rated Torque	1699 gf·cm
Stall Torque	15658.5 gf·cm
Rated Power	3488 W
Max Efficiency	52.560 %
Gearbox Length	127 mm
Gear Ratio	13 :1
Number Of Gear Stages	3
Max Continuous Torque	10 gf·cm
Instantaneous Break Torque	30 gf·cm
Backlash	3 °
Operating Temperature Range	-30 ~ 65 C
Working Lifespan	600 hours
